Ingot Attributes & Customer Settings:
sapphire bearing parts with hole, Al2O3 single crystal glass, sapphire optical glass ingots, sapphire optical rods, sapphire optical stick, Al2O3 single crystal glass lens, optical glass ingots by sapphire, sapphire optical rods
Synthetic Sapphire is a single crystal form of corundum, Al2O3, also known as alpha-alumina, and single crystal Al2O3, have 9.0 hardness. Sapphire is aluminium oxide in the purest form with no porosity or grain boundaries, making it theoretically dense.
The combination of favourable chemical, electrical, mechanical, optical, surface, thermal, and durability properties make sapphire a preferred material for high performance system and component designs. For various semiconductor applications, sapphire is the best choice in comparison with other synthetic single-crystals.
| Industrial Sapphire Wafer Specifications | |
|---|---|
| Product name | industrial sapphire wafer |
| sapphire optical lens chemical formula | AL2O3 |
| Crystal structure | Hexagonal |
| Hardness Mohs | 9H |
| Compressvise strength | Gpa 2.0 |
| Density(20ºC) | 3.98g/cm³ |
| Fusion point | 2040ºC |
| Boiling point | 2980ºC |
| Coefficient of Thermal Expansion | α=5.8×10⁻⁶ /K |
| Specific heat | 0.418W.s/g/k |
| Thermal conduction | 25.12W/m/k(@100°C) |
| Optical transmission range | 0.17-5.5μm |
| Transmission(0.3~5um) | 85-88% |
| Refractive index | no=1.768nd |
| ne=1.76nd | |
| dn/dt | 13×10⁻⁶/K(@633nm) |
| Permittivity | 11.5(//c), 9.3(⊥c) |
Sapphire Washers, Sapphire Windows, Sapphire Bearings, Sapphire Rods, Sapphire Tubes, Ruby sapphire wafer, dome sapphire, Sapphire insulation Film, Sapphire ball lens, Sapphire/ruby ball
| Specifications Sheet | |
|---|---|
| Diameter (Φmm) | 8.0, 10.0, 12.7, 15.0, 20.0, 25.4, 30.0 |
| Thickness (mm) | 0.5, 1.0, 2.0 |
| Diameter Tolerance (mm) | +0.0/-0.2 (General), +0.0/-0.1 (High Precision) |
| Thickness Tolerance (mm) | ±0.2 (General), ±0.05 (High Precision) |
| Clear Aperture | >75% (Small Size), >90% (Large Size) |
| Parallelism | 3 min. (General), 10 sec. (High Precision) |
| Surface Quality: Scratch/Dig | 80/50 (General), 40/20 (High Precision) |
| Flatness (per 25mm@633nm) | λ(General), λ/4 (High Precision) |
| Bevel (face width x 45º) | <0.25mm |
| Coating | Upon customer's request |
| Refractive index (nd) | 1.768 |
| Coefficient of dispersion (Vd) | 72.2 |
| Density (g/cm3) | 3.97 |
| TCE(μm/mºC) | 5.3 |
| Soften Temperature(ºC) | 2000 |
| Knoop hardness(kg/mm2) | 2200 |
